Mill Size Balers
For those customers with larger quantities of cardboard and polythene to dispose of, a mill size baler will compact and eject your waste. This can be resold - resulting in an income from recycling.
 Technical Specifications
Baler Dimensions
Height: 3.00m
Width: 1.73m
Depth: 1.0m
Weight: 1300kgs
Transportation Height: 2.3m
Power Supply: 3 Phase 400 Volt
Motor: 11 kw 32 amp
Pressing Force Up: to 25 Tonnes
Noise Level: 75 Decibels
Bale Dimensions
Height: 1.0m
Width: 1.2m
Depth: 0.8m
Weight: 450 Kgs (depending on type of material used)
Cycle Time: 40 seconds
Features
•Bale weight output up to 450 Kgs
•Produces mill size bale
•Fully automated bale ejector makes ejection clean and simple
•Ideal for use where there are large volumes of material
•Retaining claws to prevent spring back
• CE Marked
 Technical Specifications
Baler Dimensions
Height: 3.3m
Width: 2.1m
Depth: 1.1m
Weight: 1650 Kgs
Transportation Height: 2.5m
Power Supply 3 Phase: 400 v
Motor: 11 Kw
Pressing Force: up to 50 tonnes
Noise Level: 74 dB
Loading Aperture Sizes
Height: 0.8m
Width: 1.5m
Bale Dimensions
Width: 1.5m
Depth: 0.76m
Height: 1.2m
Weight: 500 Kg (depending on type of material used Cycle 40 sec
Features
•Bale weight output up to 550 Kg
•Fully automated bale ejector makes bale
ejection clean and simple
•Produces an export size bale
•Ideal for use where there are large volumes of material for baling
•5 wire tying for a secure bale
•Retaining claws to prevent spring back
• CE Marked
 Technical Specifications
Baler Dimensions
Height: 3.3m
Width: 2.1m
Depth: 1.4m
Weight: 1930 Kgs
Transportation Height: 2.5m
Power Supply 3 Phase: 400 Volt
Motor: 11 Kw 32amp
Pressing Force: Up to 50 Tonnes
Noise Level: 74 Decibels
Loading Aperture Sizes
Height: 0.8m
Width: 1.5m
Bale Dimensions
Height: 1.1m
Width: 1.5m
Depth 1.1m
Weight: Up to 650 Kg (depending on type of material used)
Cycle Time: 40 seconds
Features
•Bale weight output 650 Kgs
Largest heavy duty machine in the range
•Fully automated bale ejector makes bale
ejection clean and simple
•Large loading aperture
•Ideal for use where there are large volumes ofmaterial for baling
•5 wire tying for a secure bale
•Retaining claws to prevent spring back
• CE Marked
For more information or the technical specifications of the recycling plant, please contact DM Recycling Services and we will be please to help however we can.
|
